What is LED High Bay Lighting?

LED high bay lights are designed to light up spaces with high ceilings, such as warehouses, gyms, barns, and supermarkets.

Type of High Bay Light Fixtures:

• Linear LED Highbay

• Single Panel LED Linear High Bay Light



Feature:

1. 22 gauge galvanized steel housing with highly reflective, matte powder-coated paint.
2. High transmission frosted/clear acrylic lens provides a uniform lighting surface while maximizing the total generated light.
3. Specular reflector with high reflectance- Luminaires are available in 2 feet and 4 feet.
4. 120-degree beam angle even lighting distribution.
5.  Available in a wide range of color temperatures.
6.  Ambient temperature: -20℃ to 50℃.
7. Suitable for damp location use.
8. 5-year limited warranty.
9. Smooth -10V DC dimming feature and compatible with a wide variety of dimmers.

Installation Step:

Always turn off the power supply from the main circuit breaker first!

- Clip the brackets to the slots of the fixture.

- Attach provided v-Hooks to brackets.

- Attach the provided chain to the v-hooks and mounting surface.

NOTE:

Purple and pink lead inside the driver compartment are 0-10v (low-voltage) dimming leads, connected to dimming low-voltage wiring only.

Clean all residues/fingerprints from the new LED high bay and lens. Double-check all hanging hardware before moving on to the next installation.

•  Twin-Panel LED Linear High Bay Light

Installation Step:

Always turn off the power supply from the main circuit breaker first!

- Clip the brackets to the slots of the fixture.

- Attach provided v-Hooks to brackets.

- Attach the provided chain to the v-hooks and mounting surface.

NOTE:

Purple and pink lead inside the driver compartment are 0-10v (low-voltage) dimming leads, connected to dimming low-voltage wiring only.

Clean all residues/fingerprints from the new LED high bay and lens. Double-check all hanging hardware before moving on to the next installation.

• Twin-Panel Adjustable LED Linear High Bay Light

Feature:

1. 22 gauge galvanized steel housing with highly reflective, matte powder-coated paint.
2. High transmission frosted/clear acrylic lens provides a uniform lighting surface while maximizing the total generated light.
3. Specular reflector with high reflectance- Luminaires are available in 2 feet and 4 feet.
4. 120-degree beam angle even lighting distribution.
5.  Available in a wide range of color temperatures.
6.  Ambient temperature: -20℃ to 50℃.
7. Suitable for damp location use.
8. 5-year limited warranty.
9. Smooth -10V DC dimming feature and compatible with a wide variety of dimmers.

Installation Step:

Installation method of hanging chain:

- Take out the fixture and installation accessories.

- First buckle the suspending hook on the chain, then hang the hanging chain on the desired installation position of the fixture. Open the cover of the power box and take out the input wire inside the fixture. Hook the hanging hooks tothe mounting holes on both sides of the power box.

- The metal pipe passes through the KO hole of the power box cover and locks it tightly. After connecting the wires, lock the rear cover of the power box.

- Complete the installation.

Installation method of circular pipe（Optional):

- Take out the fixture and accessories (The accessories include Ceiling Bracket*1, Side Cover*2, and Screws*4. Please note these accessories need to be purchased by the user separately ). First, fix the user's ceiling box and one end of the circular pipe on the ceiling, pass the wire on the ceiling through the inside of the circular pipe, and then lock the ceiling bracket to the other end of the circular pipe through a nut.

-  Open the back cover of the fixture and take out the input wire, then snap the fixture into the ceiling bracket, and lock both sides with screws.

- Connect the input wire of the fixture with the wire passing through the circular pipe.

- Lock the side covers on both sides of the ceiling bracket with screws.

Installation method of ceiling mounting（Optional):

- Take out the fixture and installation accessories (Ceiling Bracket*2, Screws*12, Conversion Board*2, Please note these accessories need to be purchased by the user separately, due to different installation environments, the user needs to follow the rail specifications purchase suitable screws and nuts ). Lock the conversion board inside the ceiling bracket with screws, and then fix the ceiling bracket to the rail with screws and nuts

- Open the back cover of the fixture. take out the input wire and pass through the k0 hole of the back cover to connect with the main power.

- Re-fix the back cover on the fixture, then snap the fixture into the ceiling bracket and lock both sides with screws to complete the installation.

The Difference Between 3 Types of Linear High Bay Light Fixtures

	Single Panel	Twin-Panel	Twin-Panel Adjustable
Lighting Effects	Delivers bright and uniform illumination	Achieve higher light output	Customizable lighting angles
Types of Lighting	Task lighting Ambient lighting	Ambient lighting	Accent lighting Task lighting Ambient lighting
Wattage	About 150-300W	About 150-210W	About 220W
CCT	5000K Non-adjustable	4000K,5000K Adjustable	5000K Non-adjustable
Usage Occasion	Industrial Lighting Commercial Lighting	Industrial Lighting Commercial Lighting	Industrial Lighting Commercial Lighting

• UFO High Bay

Feature:

1. Precision die-cast aluminum housing, stainless steel hardware.
2. Extruded aluminum heat sink with vent inside for cool running operation in a multitude of ambient environments.
3. 60°,70°/85°/100°, 80°, 120° degree beam angles even lighting distribution.
4. Rotable, plane, nailing lens option.
5. Ambient temperature: -34℃ to +54℃.
6. 5-year limited warranty
7. Smooth 0- 10V DC dimming feature and compatible with a wide variety of dimmers.

 Type of High Bay Light Fixtures:

A Style Installation:

1). Hooking Mounting :

- Connect the black wire(Live Wire), white (Neutral wire), and green wire (Ground) to the appropriate wire inside the junction box.

- To make the lamp dimmable, please connect the 0-10V dimmer( not included) with the dimming signal of the lamp, and connect the DIM+ port and DIM- port with the corresponding line on the dimmer.

2). Ceiling-Mounted Installation (Using optional U Mount Bracket) :

- To install the optional U bracket on the luminaire, begin by attaching the L-shaped U mounting brackets on the luminaire.

- Next, attach the U bracket to the L-shaped U mounting brackets.



• Linear LED High Bay and UFO High Bay Light Comparison



- Similarity:

01) Installation Site:

Fixed on high ceilings in commercial or industrial locations.

02) Unbeatable Illumination

03) Lighting Application Site:

-- Storage, Factories, Warehouses, and other commercial locations.

-- Airport hangars, Schools, Gymnasiums, and other public place.

-- The most common place to use it is the factory.

04) Low Operating Costs

- Differences:

01) Appearance:

-- One is linear and the other is circular.

02) Illuminated Area:

-- Linear High Bay Lighting Fixture has a wider and more uniform lighting range than Round High Bay Lighting Fixture.

03) Function:

	Linear High Bay Lights	Round High Bay Lights
CCT	Non-adjustable： Only have 5000K Adjustable: Have 2CCT	Adjustable: Have 2CCT or 3CCT
Wattage	About 150-300W Adjustable	About 150-300W Adjustable
Usage Occasion	Industrial Lighting Commercial Lighting	Industrial Lighting



Do I need high bay lights?

Meet the Following Requirements:

1. Very bright light intensity is required.
2. The ceiling is very high from the floor.

How to Choose LED High Bay Lights?

• Where do I need to use High Bay fixtures？

Common places and requirements are as follows:

Application	High	Lumens	Ra	CCT	Glare
Commercial and Retail	15-18ft	13,000 to 19,000	CRI 80+	4000K to 5000K	22
Warehousing	20-30ft	20,000 to 29,000	CRI 80+	4000K to 5000K	22
Storage	30-40ft	30,000 to 39,000	CRI 70+	4000K	22

 Note: for reference only

• What Kind of High Ceilings Lighting Fixtures Do You Need?

UFO High Bays and Linear High Bays have similar lighting effects, which means you can choose it as you prefer.

• How Many Highbay LED Lights Do I Need?

The number of lights is mainly affected by the following points:

1. Size of the Area: A larger area usually requires more lights.
2. Ceiling Height: The higher the ceiling, the more lights you might need.
3. Lighting Purpose: Refined work lighting requires more lamps than general ambient lighting.

	SKU	Wattage	Lamp Quantity
Normal Brightness	EDUFO26/2778150C30ED-4 EDHB24/155W/5000K EDHBS23/155W/50K/MS	150/200/240 155 155	12 to 32pcs
Normal brightness with energy-saving	MEUHB-100/125/150-40/50K-WH	100/125/150	12 to 32pcs
High brightness	MEUHB-150/200/240-40/50K EDG2LHB2FT3LF8155 EDG3LHB2FT4L	150/200/240 300 210	16 to 48pcs

 Note: for reference only

•  How Far Apart Should High-bay LED Lights Be?

Installation Height	Luminaire Distance
15 to 20 feet	12 to 14 ft spacing
20 to 30 feet	16 to 18 ft spacing
Over 30 feet	20 to 25 ft spacing



• How Many Lumens for High Bay LED Lights? How Many Watts Are High Bay Lights?

Ceiling Height	Use a fixture-rated	SKU
15 to 20 feet	15,000 to 19,000 lumens	MEUHB-100/125/150-40/50K-WH
20 to 30 feet	20,000 to 29,000 lumens	EDHB26/210W/4PK EDHB24/155W/5000K EDHBS23/155W/50K/MS-4PK
30 to 40 feet	30,000 to 39,000 lumens	MEUHB-150/200/240-40/50K-WH MEUHB-150/200/240-40/50K EDUFO26/2778150C30ED-4
Over 40 feet	40,000 lumens & up	EDG2LHB2FT3LF8155

• Additional Content:

1)Heat Radiation & Heat Dissipation:

Lighting Fixtures will generate heat during the working period. If the lights generates too much heat or poor heat dissipation, it will not only affect the lighting effect and service life of the lights but also lead to the deformation of the lights and even the failure of electronic devices.

2)Safety and Product Certification:

• DLC

• UL Classification

• UL Listed

• ETL Listed

Regular lamps are safer and will give employees more sense of security.

3)Wattage Adjustable:

Energy saving is also one of the important factors in our selection of lamps, adjustable wattage can help us save electricity.

4)Color Temperature Adjustable:

5)Smooth Dimming

6)Length and Scope of Warranty

Good after-sales is also very important for lamps.
