The Introduce of Wallpack

, by Kelly Yao, 8 min reading time

What Is A Wall Pack?

The wall pack light is fixed to a building's exterior and provides area lighting.

outdoor led wall pack

Benefits of Using LED Wall Packs:

LED wall pack lights have their benefits compared the traditional lighting fixtures:

  1. Energy Conservation: LED lighting technology is energy-efficient, consuming significantly reduce 85% electricity compared to traditional lighting.
  2. Long Lifespan: LED wall pack lights often last up to 50,000 hours or more.
  3. Reducing Maintenance Costs: High reliability and low maintenance cost.
  4. Durability:  Constructed out of heavy duty die-cast aluminum with architectural baked polyester powder coating for lasting durability.
  5. Safe: Providing visibility in outdoor areas and increasing security.

What Are The Different Types Of Wall Packs?



75W LED Eco Commercial Wallpack,5000K,8635 lumens
 Name: 5000K 75W LED Eco Commercial Wallpack
 SKU: EDWP-075W-50K
 Material: Aluminum & Glass
 Wattage: 75 Watte
 Brightness: 8635 Lumens
 Input Voltage: 120-277 Vac
 Certifications: FCC, ETL, DLC
 Life Hours: 50,000 Hrs

 <<<<<<<< Click to learn more

  • Full Cut-off LED Wall Pack

- Heavy Duty die-cast aluminum housing with anti-Orrison texture architectural baked polyester powder coating

- Durable clear/frosted opal glass with cast aluminum guard

- Aluminum extruded heat sink designed to facilitate heat dissipation to reduce LED junction temperature for maintaining lighting output and life span of the LED

- 120-277V lnput, 50/60Hz, PF > 0.9, CRI>70

- 140-degree beam angle even lighting distribution

- Available in 4000/5000K

- Ambient temperature: -25C to +54C

- Humidity: 20-85%RH, non- condensing

- Smooth dimming feature and compatible with a wide variety of dimmers

  • CCT & Wattage Adjustable





3CCT 3Wattage Adjustable Wallpack

EDWP80100120W-3CCT EDWP405060W-3CCT  EDWP0130/40/50/60W
120-277 Vac  120-277 Vac 120-277 Vac
80/100/120 Watt 40/50/60 Watt 30/40/50/60 Watt
11200/14000/16800 Lumens 5600/7000/8400 Lumens 3750/5000/6250/7500  L umens
3000/4000/5000K 3500/4000/5000K 3500/4000/5000K
ETL, DLC ETL, DLC FCC, ETL, DLC
<<<<Click to learn more <<<<Click to learn more <<<<Click to learn more

Wall Pack Fixtures Installation:



  • Junction Box Mounting:

Install of Wall Pack Fixtures - Junction Box MountingStep 01:

Unscrew the screws on the right side using a suitable screwdriver. Separate the male and female connectors, then remove the reflector from the back plate

Step 02:

Create four holes by knocking out the four points indicated in A/B/C/D. Unscrew Bolt(1) from the bottom center. (Note: the other three Bolts (2)/(3)/(4) can be unscrewed depending on your requirements during the wiring process.)

Step 03:

Run the main power wire from the water-proof J-box through the hole(H), then lock the back plate to the water-proof J-box using four screws. Add the gasket to the round area from outside if needed.

Step 04:

Use the hinge to lock the reflector to the back plate firmly, then connect the main power. Black wiring to L, White to N, Green to G (see diagram below.) Next, connect the male and female connectors together. Finally, use a suitable screwdriver to connect the reflector to the back plate.
  • Conduit Mounting:

Install of Wall Pack Fixtures -  Conduit Mounting

Step 01:

Unscrew the screws on the right side using a suitable screwdriver. Separate the male and female connectors, then remove the reflector from the back plate

Step 02:

Unscrew the right-side Bolt(5). Drill three holes in E/F/G using a suitable drill. Next, fasten the back plate to the wall with the three screw components. (Make sure to waterproof three open holes-E/F/G.)

Step 03:

Run the main power through the right hole and then finish the wiring (Black wire - L, White wire -N, Green wire - G) See the wiring diagram on page 2.

Step 04:

Use the hinge to lock the reflector to the back plate firmly. Next, connect the male and female connectors. Finally, use a suitable screwdriver to connect the reflector to the back plate.

How Do I Choose An LED Wall Pack?

  • Material

Luminaire Shell Material:

- Heavy-duty die-cast aluminum housing with anti-Orrison texture architectural baked polyester powder coating.

- Aluminum extruded heat sink designed to facilitate heat dissipation to reduce LED junction temperature for maintaining lighting output and life span of the LED

Lampshade Material:

Durable clear/frosted opal glass with cast aluminum guard

  • Brightness



Brightness Wallpack Lighting Fixture

Lumens measure how much light you are getting from the lighting fixture.

A larger value indicates a brighter light and a smaller value indicates a dimmer light.

The most LED wall pack light common lumen range is 3,300lux to 7100lux that it is the most users choose.

Besides, with the development of lighting technology, more and more lighting fixtures can choose the brightness they want according to their needs.

Adjustable Luminance vs Not Adjustable Luminance:

Benefit 1: Adjustable luminance can easily suit the needs of the space.

Benefit 2: Adjustable luminance can easily create the right ambiance for different situations.

Benefit 3: Saving energy can bring considerable economic benefits in the long run

  • Wattage

Electrical power is usually measured in watts. The lower the wattage, the less the amount of electrical energy that an electrical appliance or piece of equipment uses over a while.

There are several common types:

  1. The wattage is not adjustable
  2. 3 Wattage Selection
  • Color Temperature (CCT)

Color temperature refers to people's visual feelings or impressions of light, and its unit is K.

The higher the K value, the whiter the light color, the more blue or purple, which will make people have cold and cool visual feelings, commonly known as cold light.

The lower the K value, the light shown will be yellow and red, and the warm color light will give people a warm feeling, commonly known as warm color light.

It will play a role in regulating the human senses.

CCT

There are several common types:

Non-CCT 3CCT 4CCT 5CCT
The color temperature cannot be adjusted 3 different CCT options for LED light fixture control 4 different CCT options for LED light fixture control 5 different CCT options for LED light fixture control

Which CCT Is Best?

2700K/3000K/3500K/4000K/5000K - 5CCT

In General:

CCT Situation
2700K Warm White Residential lighting, Bars
3000K Soft White Residential lighting, Garages, Basements
3500K Natural White Residential lighting, Commercial lighting, Office, School
4000K Cool White Residential lighting, Commercial lighting, Garages, Classroom
5000K Daylight Commercial lighting, Workshops, Warehouse



  • 0-10V Dimmable

0-10V Dimmable

What Are The Advantages Of 0-10V Dimming?

  1. Reduce the power of the lamp when working
  2. Extend the service life of lamps

<<<<<<<< Learn more about dimmable lighting fixtures

  • Easy For Installation

 1. Installation Height:

Most wall packs are designed to be mounted between 10–20ft.

 2. Design & Style:

Choose the style of wallpack lights that matches the space's architecture and decor.
